Set N+1 Hot Spare for Hybrid SAN

You can form an N+1 hot spare system with several Recording Servers. The system consists of several host servers and a spare server. When the host server fails, the spare server switches into operation, and thus increasing the video storage reliability of HikCentral Professional.

  • Make sure the Hybrid Storage Area Networks you are going to use are correctly installed and connected to the network as specified by the manufacturers. Such initial configuration is required in order to be able to connect the devices to the HikCentral Professional via network.

  • At least two online Hybrid Storage Area Networks should be added to form an N+1 hot spare system.

Note:

  • The N+1 hot spare function is only supported by Hybrid Storage Area Networks and NVRs. For details about configuring N+1 hot spare system with NVRs, see Set N+1 Hot Spare for NVR.

  • The spare server cannot be selected for storing videos until it switches to host server.

  • The host server cannot be set as a spare server and the spare server cannot be set as a host server.

  1. In the top left corner of Home page, select > Basic Management > Device.
  2. Click Device and Server > Recording Server > to enter the N+1 Configuration page.
    Figure 1 N+1 Configuration Page
  3. Click Add to set the N+1 hot spare.
  4. Select a Hybrid Storage Area Network in the Spare drop-down list to set it as the spare server.
  5. Select the Hybrid Storage Area Network(s) in the Host field as the host server(s).
  6. Click Add.
    Note:

    The recording schedules configured on the Hybrid Storage Area Network will be deleted after setting it as the spare Recording Server.

  7. Optional: After setting the hot spare, you can do one or more of the following.
    Option Description

    Edit

    Click on the Operation column, and you can edit the spare and host settings.

    Delete

    Click on the Operation column to cancel the N+1 hot spare settings.

    Note:

    Canceling the N+1 hot spare will cancel all the host-spare associations and clear the recording schedule on the spare server.

    Send Recording Schedule

    Click on the Operation column to send the recording schedule on the host server to the spare one again if the host server failed to send the recording schedule to spare server.
